- Plataforma: INTEL Socket 1150
- Chipset: Intel® H81
- Suporte CPU : Intel 4th generation Core™ i7 / Core™ i5 / Core™ i3 / Pentium® / Celeron® / Xeon® Processors (CPU up to 95 watts)
- Memória: 1066 / 1333 / 1600 / 1860MHz - Dual Channel DDR3 1066 / 1333 / 1600 / 1860MHz Dimm - 2 x Memory Slots (Max. capacity of system memory 16GB)
- Gráficos Integrados: Integrated Graphics Processor
- PCI/PCI-E Slots: 1 x PCI Express x16 2.0 slot, 1 x PCI Express x1 slot
- SATA: 3 x SATA3, 1 x M.2 (PCIe NVMe Gen3 x4 & SATA3)
- Áudio: Realtek 662 on board, Supports 6-channel audio-out
- LAN: Realtek RTL8111 Gigabit Ethernet on board
- Painel Traseiro: 1 x HDMI Port; 1 x D-Sub (VGA) Port; 2 x USB 3.0 Ports; 4 x USB 2.0 Ports; 1 x RJ-45 LAN Port with LED; 3 x HD Audio Jacks (Line in / Front Speaker / Microphone);
- Painel Frontal: 1 x USB 2.0 pinheader (supports additional 2 USB 2.0s), 1 x USB 3.0 pinheader (supports additional 2 USB 3.0s); 1 x Front Panel Audio pinheader
- BIOS: UEFI
- Formato: Micro-ATX
